Synera · Partnership

Add-ins for the Synera platform.

A suite of Raphos add-ins that bring physics, optimization and connectivity to Synera — the visual-programming and automation platform for engineering.

The Synera visual-programming platform — the automation environment the Raphos add-ins extend
The Synera visual-programming platform — the automation environment the Raphos add-ins extend

Synera (formerly ELISE) is a low-code, visual-programming platform that lets engineering teams capture their know-how as automated workflows — connecting CAD, CAE, PLM and data into a single, repeatable graph. Raphos builds and maintains a family of add-ins that extend Synera with capabilities our clients asked for: a fast physics solver, an optimizer, automatic cable and pipe routing, research-grade mesh and point-cloud processing, productivity tools, and connectors to external simulation, MATLAB and the Microsoft 365 / Power Platform stack.

Each add-in is developed in close partnership with the Synera team and tuned for production use — robust, fast and engineered to slot into real automation pipelines rather than one-off scripts. Together they let designers go from geometry to a validated, optimized result without leaving the Synera canvas.

In this area

11 projects.

Open any project for the full write-up, capabilities and links.

A tensile membrane form-found by the Raphos Physics solver

Synera add-in · Solver

Raphos Physics

Dynamic-relaxation / spring-particle physics solver for form-finding and simulation inside Synera.

  • Dynamic relaxation
  • Form-finding
  • Spring-particle
  • Simulation
The Raphos Optimizer running a neural-network-driven optimization inside Synera

Synera add-in · Optimization

Raphos Optimizer

Optimization engine for Synera: gradient-based and heuristic solvers for engineering design problems.

  • Optimization
  • Genetic algorithms
  • Gradient descent
  • Multi-objective
The Route Cable node in Synera bundling two cables past a bracket, bending around the obstacle within their limits

Synera add-in · Routing

Raphos Bundle

Automatic cable and pipe-harness routing for Synera: A* corridor search plus constrained optimization, with hard requirements instead of tuned weights.

  • Cable routing
  • Path planning
  • Optimization
  • Constraints
A selection of Raphos Tools geometry components on the Synera canvas

Synera add-in · Toolkit

Raphos Tools

Productivity and geometry utilities for Synera — the components engineers reach for daily.

  • Geometry
  • Data
  • Utilities
  • Productivity
The Heat Geodesic Field example in Synera: distance along the surface from one vertex, coloured onto the dodo demo mesh

Synera add-in · Geometry processing

Raphos Geometry

40 nodes for remeshing, repair, geodesics, curvature, UV unwrapping and point-cloud reconstruction, built on Geogram, Geometry Central and libigl.

  • Meshing
  • Point clouds
  • Geodesics
  • UV unwrapping
  • C++
A conjugate-heat-transfer CFD result on cooling channels, run on SimScale from a Synera workflow

Synera add-in · Connector

SimScale Connector

Connector linking Synera workflows to SimScale’s cloud simulation (CFD / FEA).

  • CFD
  • FEA
  • Cloud simulation
  • Automation
The Raphos MATLAB node running a linear fit: typed inputs go in, workspace variables come back as outputs and feed a chart

Synera add-in · Connector

MATLAB Connector

Connector running MATLAB scripts via the Automation Server (COM) and exposing workspace variables as Synera node outputs.

  • MATLAB
  • Scripting
  • Data exchange
  • Automation
A formatted report generated automatically from a Synera workflow via the MS Office Connector

Synera add-in · Connector

MS Office Connector

Connector for building and reading Microsoft Word and PowerPoint documents from Synera, with PDF export.

  • Word
  • PowerPoint
  • Reporting
  • Templates
Synera streaming live Microsoft Teams messages — simulation-complete notifications from the Raphos Teams add-in

Synera add-in · Connector

Raphos Teams Connector

Connector linking Synera to Microsoft Teams — notify people and channels, share reports, and trigger runs from messages.

  • Microsoft Teams
  • Notifications
  • Automation
  • Reporting
Microsoft Power Automate — the cloud-flow service the connector triggers straight from a Synera workflow

Synera add-in · Connector

Power Automate Connector

Connector linking Synera to Microsoft Power Automate: fire cloud flows via webhook or the management API, and watch run history.

  • Power Automate
  • Cloud flows
  • Automation
  • Integration
A Synera graph that signs in to Power BI, builds a table schema, creates a push dataset and appends result rows

Synera add-in · Connector

Power BI Connector

Connector pushing Synera-generated data into Microsoft Power BI datasets, so engineering workflows feed live dashboards.

  • Power BI
  • Dashboards
  • Reporting
  • Data exchange
